HDSP-U313
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Yellow CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $3.72
Unit Price: USD $3.720759
≥1 USD $3.720759
≥200 USD $1.48489
≥400 USD $1.435
≥1000 USD $1.411368
Inventory: 8015
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.209, 5.30mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2014
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 90°C
Min Operating Temperature -20°C
Color Yellow
Subcategory LED Displays
Number of Functions 1
Depth 7.1mm
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 80mW
Voltage - Forward (Vf) (Typ) 2.2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 2.74 mcd
Millicandela Rating 2.74mcd
Wavelength - Peak 583nm
Display Type 7-Segment
Reverse Voltage 50V
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.31 8.00mm
Common Pin Common Cathode
Dominant Wavelength 586 nm
Dimensions
Height 10.9982mm
Viewing Area (height) 8mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
