HDSP-U303

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description Displays Module 1DIGIT 8LED Yellow CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 1083
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 8mm
Height 10.9982mm

Technical

Dominant Wavelength 586 nm
Common Pin Common Cathode
Digit/Alpha Size 0.31 8.00mm
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 583nm
Luminous Intensity 2.74 mcd
Current - Test 20mA
Forward Current 5mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 80mW
Element Configuration Common Cathode
Number of Elements 8
Depth 7.1mm
Number of Functions 1
Subcategory LED Displays
Color Yellow
Min Operating Temperature -20°C
Max Operating Temperature 90°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
Published 2014
Packaging Bulk

Physical

Number of Pins 10
Package / Case 10-DIP (0.209, 5.30mm)
Mount Through Hole

Supply Chain

Factory Lead Time 22 Weeks
