HDSP-U213-CD000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
7-Segment 1 SMART/NORMAL 7SEG NUMERIC LED DISPLAY Red LED Character Numeric Display Module 2.5V 20mA 5.39mcd 105mW
PDF
/
Inventory: 7033
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Viewing Area (height) 8mm
Height 10.9982mm
Technical
Dominant Wavelength 626 nm
Common Pin Common Cathode
Digit/Alpha Size 0.31 8.00mm
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 30V
Display Type 7-Segment
Wavelength - Peak 635nm
Millicandela Rating 5.39mcd
Luminous Intensity 5.39 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation 105mW
Element Configuration Common Cathode
Number of Elements 8
Depth 7.1mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 90°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
Published 2014
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.209, 5.30mm)
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
