HDSP-U103
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.209, 5.30mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $4.4
Unit Price: USD $4.4
≥1 USD $4.4
≥10 USD $3.11168
≥100 USD $2.548788
≥500 USD $2.148678
≥1000 USD $1.970866
≥3000 USD $1.88936
Inventory: 1152
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.209, 5.30mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2012
Size / Dimension 0.433 Hx0.280W x 0.197 D 11.00mmx7.10mmx5.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 90°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 7.1mm
Operating Supply Voltage 1.8V
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 37mW
Voltage - Forward (Vf) (Typ) 1.7V
Forward Current 15mA
Current - Test 5mA
Luminous Intensity 3.6 mcd
Wavelength - Peak 645nm
Display Type 7-Segment
Reverse Voltage 15V
Forward Voltage-Max 2.2V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.31 8.00mm
Common Pin Common Cathode
Dominant Wavelength 637 nm
Character Width 4mm
Dimensions
Height 10.9982mm
Viewing Area (height) 8mm
Character Height 8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
