HDSP-N103
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-N103 7-Segment LED Display, 1, 20 mm, Red, Common Cathode, 3.5 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $7.37
Unit Price: USD $7.3656
≥1 USD $7.3656
≥10 USD $5.34336
≥100 USD $4.41511
≥500 USD $3.86672
≥1000 USD $3.65581
≥3000 USD $3.571445
Inventory: 889
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 20mm
Viewing Area (height) 20.32mm
Height 27.686mm
Technical
Character Width 20.3mm
Dominant Wavelength 637 nm
Common Pin Common Cathode
Digit/Alpha Size 0.80 20.32mm
Number of Characters 1
Reverse Voltage 15V
Display Type 7-Segment
Wavelength - Peak 645nm
Luminous Intensity 3.5 mcd
Current - Test 5mA
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 37mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 1.8V
Depth 19.96mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
Published 2005
Packaging Bulk
Physical
Number of Pins 13
Package / Case 18-DIP (0.600, 15.24mm), 12 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
Alternative Model
