HDSP-H153

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 14.2MM CC RED RHD RHD
PDF
/
Buying Options
Total Price: USD $3.86
Unit Price: USD $3.8632
≥1 USD $3.8632
≥10 USD $2.73064
≥100 USD $2.236546
≥500 USD $1.885453
≥1000 USD $1.72942
≥3000 USD $1.657902
Inventory: 86
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Character Height 14.22mm
Viewing Area (height) 14.22mm
Height 8mm

Technical

Background Color Grey
Dominant Wavelength 637 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Forward Voltage-Max 3V
Reverse Voltage 15V
Display Type 7-Segment
Power Consumption 96mW
Wavelength - Peak 645nm
Luminous Intensity 16 mcd
Current - Test 20mA
Forward Current 100mA
Viewing Angle 100 °
Voltage - Forward (Vf) (Typ) 1.8V
Power Dissipation 96mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 2V
Depth 17.02mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
Published 2010
Packaging Tube

Physical

Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Contact Plating Copper, Silver, Tin

Supply Chain

Factory Lead Time 16 Weeks
