HDSP-B10G
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-B10G 7-Segment LED Display, 4, 14.22 mm, Green, Common Anode, 4.5 mcd, 20 mA
PDF
/
Inventory: 7146
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Package / Case 12-DIP (0.600, 15.24mm)
Number of Pins 12
Technical
Packaging Bulk
Published 2002
Size / Dimension 0.752 Hx2.016W x 0.315 D 19.10mmx51.20mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Green
Subcategory LED Displays
Depth 19.1mm
Operating Supply Voltage 2.2V
Number of Elements 30
Element Configuration Common Anode
Power Dissipation 65mW
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 4.5 mcd
Millicandela Rating 4.5mcd
Wavelength - Peak 568nm
Power Consumption 65mW
Display Type 7-Segment Clock
Reverse Voltage 5V
Forward Voltage-Max 2.6V
Number of Characters 4
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Dominant Wavelength 573 nm
Dimensions
Height 19.1008mm
Viewing Area (height) 14.22mm
Character Height 14.22mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
