HDSP-B07G

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description Displays Panel 4DIGIT 30LED Green CC 12-Pin DIP Tube
PDF
/
Inventory: 5070
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 22 Weeks

Physical

Mount Through Hole
Package / Case 12-DIP (0.600, 15.24mm)
Number of Pins 12

Technical

Packaging Bulk
Published 2002
Size / Dimension 0.752 Hx2.016W x 0.315 D 19.10mmx51.20mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Green
Subcategory LED Displays
Depth 19.1mm
Number of Elements 30
Element Configuration Common Cathode
Power Dissipation 65mW
Voltage - Forward (Vf) (Typ) 2.2V
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Forward Current 25mA
Current - Test 20mA
Luminous Intensity 4.5 mcd
Wavelength - Peak 568nm
Display Type 7-Segment Clock
Reverse Voltage 5V
Forward Voltage-Max 2.6V
Number of Characters 4
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dominant Wavelength 573 nm

Dimensions

Height 19.1008mm
Viewing Area (height) 14.22mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
