HDSP-A907
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm), 7 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module Overflow 5LED Green CA 10-Pin DIP
PDF
/
Inventory: 6783
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.200, 5.08mm), 7 Leads
Number of Pins 10
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.500 Hx0.300W x 0.390 D 12.70mmx7.62mmx9.91mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green
Subcategory LED Displays
Number of Functions 0.5
Depth 7.62mm
Operating Supply Voltage 1.7V
Number of Elements 5
Element Configuration Common Anode
Power Dissipation 64mW
Voltage - Forward (Vf) (Typ) 2V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 4mA
Current - Test 10mA
Luminous Intensity 1.5 mcd
Wavelength - Peak 566nm
Display Type 7-Segment
Reverse Voltage 30V
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Anode
Dominant Wavelength 571 nm
Dimensions
Height 12.7mm
Viewing Area (height) 7.62mm
Compliance
RoHS Status ROHS3 Compliant
