HDSP-7808

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.200, 5.08mm), 7 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description Displays Module Overflow 5LED Green CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $5.15
Unit Price: USD $5.154445
≥1 USD $5.154445
≥200 USD $2.057314
≥400 USD $1.987731
≥1000 USD $1.953595
Inventory: 4491
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Height 12.7mm

Technical

Dominant Wavelength 571 nm
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters +/-1 (overflow)
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 566nm
Luminous Intensity 6.8 mcd
Current - Test 10mA
Forward Current 30mA
Power Dissipation 105mW
Element Configuration Common Cathode
Power Dissipation-Max 105mW
Number of Elements 5
Operating Supply Voltage 2.1V
Depth 7.62mm
Number of Functions 0.5
Subcategory LED Displays
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish TIN/TIN SILVER COPPER
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3/e1
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2006
Packaging Bulk

Physical

Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm), 7 Leads
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
