HDSP-5607-GH000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm), 9 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module Overflow 6LED Green CA 10-Pin DIP
PDF
/
Inventory: 7674
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm), 9 Leads
Number of Pins 10
Technical
Packaging Bulk
Published 2014
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green
HTS Code 8531.20.00.40
Subcategory LED Displays
Number of Functions 1
Depth 12.4mm
Operating Supply Voltage 2.1V
Number of Elements 6
Power Dissipation-Max 105mW
Element Configuration Common Anode
Power Dissipation 105mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 90mA
Current - Test 10mA
Luminous Intensity 2.5 mcd
Wavelength - Peak 566nm
Display Type 7-Segment
Reverse Voltage 50V
Forward Voltage-Max 2.5V
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Dominant Wavelength 571 nm
Dimensions
Height 17.018mm
Compliance
RoHS Status ROHS3 Compliant
