HDSP-3603
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Green CC 14-Pin DIP
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 199
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Number of Pins 14
Technical
Packaging Tube
Published 2011
Size / Dimension 0.750 Hx0.400W x 0.180 D 19.05mmx10.16mmx4.57mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green
Subcategory LED Displays
Number of Functions 1
Depth 10.16mm
Operating Supply Voltage 2.1V
Number of Elements 8
Power Dissipation-Max 105mW
Element Configuration Common Cathode
Power Dissipation 105mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 30mA
Current - Test 10mA
Luminous Intensity 2.7 mcd
Wavelength - Peak 566nm
Display Type 7-Segment
Reverse Voltage 50V
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Cathode
Dominant Wavelength 571 nm
Dimensions
Height 19.05mm
Viewing Area (height) 7.62mm
Character Height 7.6mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
