HDSP-3356

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 14-DIP (0.300, 7.62mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description Displays Module Overflow 6LED Hi-Eff. Red 12-Pin DIP
PDF
/
Inventory: 2893
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 10.36mm
Height 19.05mm

Technical

Character Width 10.9mm
Dominant Wavelength 626 nm
Common Pin Universal
Digit/Alpha Size 0.43 11.00mm
Number of Characters +/-1 (overflow)
Reverse Voltage 30V
Display Type 7-Segment
Wavelength - Peak 635nm
Luminous Intensity 1.48 mcd
Current - Test 5mA
Forward Current 15mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 52mW
Element Configuration Common Anode
Number of Elements 6
Depth 12.7mm
Number of Functions 0.5
Subcategory LED Displays
HTS Code 8531.20.00.40
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
Published 2006
Packaging Bulk

Physical

Number of Pins 12
Package / Case 14-DIP (0.300, 7.62mm), 12 Leads
Mount Through Hole

Supply Chain

Factory Lead Time 13 Weeks
