HDSP-0761

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 8-DIP (0.600, 15.20mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description Numeric Displays Module 1DIGIT 20LED Hi-Eff. Red 8-Pin DIP
PDF
/
Buying Options
Total Price: USD $89.9
Unit Price: USD $89.898202
≥1 USD $89.898202
≥200 USD $35.869741
≥500 USD $34.672376
≥1000 USD $34.078945
Inventory: 965
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case 8-DIP (0.600, 15.20mm)
Number of Pins 8

Technical

Packaging Bulk
Published 2008
Series HDSP-076x
Size / Dimension 0.531 Hx0.402W x 0.169 D 13.50mmx10.20mmx4.30mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Red
Additional Feature BUILT-IN MEMORY, WITH DECODER/DRIVER, TTL COMPATIBLE
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 1
Depth 13.5mm
Operating Supply Voltage 5V
Number of Elements 20
Configuration COMPLEX
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Power Dissipation 573mW
Current - Test 10mA
Forward Voltage 1.6V
Luminous Intensity 1.17 mcd
Millicandela Rating 0.06mcd ~ 1.17mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.29 7.37mm
Common Pin Common Anode
Dominant Wavelength 626 nm

Dimensions

Height 13.4874mm
Viewing Area (height) 7.4mm
Character Height 7.4mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
