HDSM-443B

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description BROADCOM LIMITED HDSM-443B 7-Segment LED Display, Blue, 20 mA, 3.3 V, 11.2 mcd, 2, 10 mm
PDF
/
Buying Options
Total Price: USD $10.57
Unit Price: USD $10.568845
≥1 USD $10.568845
≥200 USD $4.217035
≥500 USD $4.076555
≥1000 USD $4.006971
Inventory: 5947
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Package / Case 10-SMD, No Lead
Number of Pins 10

Technical

Packaging Tape & Reel (TR)
Published 2008
Size / Dimension 0.512 Hx0.772W x 0.148 D 13.00mmx19.60mmx3.75mm
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Blue
Depth 15mm
Number of Elements 16
Power Dissipation-Max 100mW
Element Configuration Common Cathode
Power Dissipation 100mW
Voltage - Forward (Vf) (Typ) 3.3V
Forward Current 20mA
Current - Test 20mA
Forward Voltage 3.3V
Luminous Intensity 11.2 mcd
Millicandela Rating 11.2mcd
Wavelength - Peak 462nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 2
Digit/Alpha Size 0.39 10.00mm
Common Pin Common Cathode
Dominant Wavelength 470 nm

Dimensions

Height 13.0048mm
Length 19.6mm
Width 19.6088mm
Viewing Area (height) 10mm
Character Height 10mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
