HDSM-291B
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISPLAY, SMD, DUAL, 7MM, BLU, CA
PDF
/
Buying Options
Total Price: USD $9.47
Unit Price: USD $9.466009
≥1 USD $9.466009
≥200 USD $3.777213
≥500 USD $3.651175
≥1000 USD $3.588156
Inventory: 5642
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Package / Case 10-SMD, No Lead
Number of Pins 11
Technical
Packaging Tape & Reel (TR)
Published 2016
Size / Dimension 0.394 Hx0.594W x 0.148 D 10.00mmx15.10mmx3.75mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Blue
Subcategory LED Displays
Number of Functions 2
Depth 12mm
Number of Elements 18
Element Configuration Common Anode
Power Dissipation 100mW
Voltage - Forward (Vf) (Typ) 3.3V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 6 mcd
Millicandela Rating 6mcd
Wavelength - Peak 462nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 4V
Number of Characters 2
Digit/Alpha Size 0.28 7.00mm
Common Pin Common Anode
Dominant Wavelength 470 nm
Dimensions
Height 10.0076mm
Viewing Area (height) 7mm
Character Height 7mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
