NHD-0216CW-AR3

Newhaven Display Intl
RoHS
/
Package Module
Category Optoelectronics / Display Modules - LCD, OLED Character and Numeric
Description Character OLED; 2x16; 760x24.5; Char OLED Module; Red; 4/8-bit Parallel,SPI,I2C
PDF
/
Inventory: 7124
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Technical

Character Format 5 x 8 Dots
Text Color Red
Character Size 5.57mm Hx2.97mm W
Outline L x W x H 76.00mm x 24.50mm x 2.50mm
Display Format 16 x 2
Dot Size 0.57mm Wx0.67mm H
Background Color Black
Display Mode Passive
Viewing Area 58.22mm L x 13.52mm W
Number of Characters 32
Display Type OLED
Interface Parallel, 8-Bit, I2C, SPI
Voltage - Supply 2.4V~5.5V
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Published 2014
Operating Temperature -40°C~85°C

Physical

Package / Case Module

Supply Chain

Factory Lead Time 18 Weeks
