RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
SW ROTRY DIP HEX W/COMP 0.1A 28V
PDF
/
Buying Options
Total Price: USD $29.35
Unit Price: USD $29.351192
≥1 USD $29.351192
≥200 USD $11.711068
≥500 USD $11.319824
≥1287 USD $11.126828
Inventory: 1698
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.385 9.78mm
Length 0.905 22.99mm
Height 9.14mm
Technical
Contact (AC) Max Power Rating R Load 2.8VA@120VAC
Body Color BLACK
Actuator Level Flush, Recessed
Washable Yes
Contact Function ON-ON
PCB Hole Count 16
Number of Switch Sections 16
Index Angle 22.5 deg
Contact Timing BREAK-BEFORE-MAKE
Illumination Type Non-Illuminated
Contact Current Rating 1A
Throw Configuration 4PDT
Electrical Life 500 Cycle(s)
Dielectric Withstanding Voltage 300VAC V
ELV Compliant
Sealing BOTTOM SEALED
Insulation Resistance 1000000000Ohm
Contact Resistance 0.1mOhm
Circuit Hexadecimal with Complement
Actuator Type Rotary for Tool
Body Breadth 9.144 mm
Lead Pitch 2.54mm
Termination Style PC Pin
Contact Finish Gold
Depth 9.47mm
Terminal Pitch 2.54mm
Orientation Straight
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
Voltage - Rated DC 50V
HTS Code 8536.50.90.65
Additional Feature SCREWDRIVER SLOT
Voltage - Rated 28VDC
Number of Positions 16
Type Switch
ECCN Code EAR99
Termination PC Pins
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Tape Seal
Published 1997
Packaging Tube
Physical
Body Material Polyester (PET), Glass Filled
Housing Material Polyester
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Beryllium Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 9 Weeks
