A6DR-0100
RoHS
RoHS compliant
RoHS compliantPackage DIP
Category Switches / DIP Switches
Description
OMRON ELECTRONIC COMPONENTS A6DR-0100 DIP / SIP Switch, SPST, Through Hole, 10 Circuits, DIP Sealed, 24 VDC
PDF
/
Buying Options
Total Price: USD $5.36
Unit Price: USD $5.3592
≥1 USD $5.3592
≥10 USD $5.11984
≥100 USD $4.339632
≥500 USD $4.2922
Inventory: 72
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Physical
Contact Material Copper, Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case DIP
Insulation Material POLYBUTYLENE TEREPHTHALATE
Weight 2.2g
Technical
Operating Temperature -20°C~70°C
Packaging Tube
Published 1998
Series A6DR
JESD-609 Code e4
Feature IP64 - Dust Tight, Water Resistant
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
ECCN Code EAR99
Number of Positions 10
Voltage - Rated 30VDC
Additional Feature SEALED CONSTRUCTION
HTS Code 8536.50.90.65
Voltage - Rated DC 30V
Current Rating (Amps) 30mA
Pitch 0.100 2.54mm Full
Orientation Straight
Terminal Pitch 2.54mm
Depth 10.75mm
Current Rating 100mA
Contact Finish Gold
Termination Style PC Pin
Body Breadth 8.9 mm
Actuator Type Piano
Circuit SPST
Contact Resistance 100mOhm
Contact Current(DC)-Max 0.1A
Sealing DUST PROOF
Max Current Rating 100mA
Dielectric Withstanding Voltage 500VAC V
Electrical Life 2,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 5000 cycles
Contact Current Rating 100mA
Contact Timing MAKE-BEFORE-BREAK
Contact (DC) Max Rating R Load .1A@5VDC
Number of Switch Sections 10
PCB Hole Count 20
Contact Function ON-OFF
Washable Yes
Actuator Level Raised
Dimensions
Length 1.079 27.41mm
Body Height 6.4mm
Actuator Length 1.75mm
Height Above Board 0.292 7.41mm
Compliance
Radiation Hardening No
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
