219-10MSTJ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / DIP Switches
Description
Slide (Standard) 219 10 Surface Mount Dip Switch 3.8mm 0.1A 20V -55C~85C
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.961473
≥1 USD $1.961473
≥200 USD $0.782488
≥500 USD $0.75623
≥1000 USD $0.744414
Inventory: 9769
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height Above Board 0.210 5.33mm
Body Height 3.8mm
Length 1.058 26.87mm
Technical
Actuator Level Raised
Washable Yes
Number of Switch Sections 10
Switch Type SLIDE DIP SWITCH
Electrical Life 2,000 Cycles
Contact Voltage(DC)-Max 20V
Sealing BOTTOM SEALED; TOP TAPE SEALED
Contact Current(DC)-Max 0.1A
Circuit SPST
Actuator Type Slide (Standard)
Body Breadth 6.7 mm
Termination Style J Lead
Contact Finish Gold
Pitch 0.100 2.54mm Full
Current Rating (Amps) 100mA
HTS Code 8536.50.90.65
Voltage - Rated 20VDC
Number of Positions 10
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals, Tape Seal
JESD-609 Code e4
Series 219
Published 2008
Packaging Tube
Operating Temperature -55°C~85°C
Physical
Surface Mount NO
Mounting Type Surface Mount
Contact Material Beryllium Copper
Supply Chain
Factory Lead Time 8 Weeks
