Package /
Category Switches / DIP Switches
Description Slide (Standard) 209 7 Through Hole Dip Switch 3.8mm 0.1A 20V -40C~85C
PDF
/
Buying Options
Total Price: USD $1.43
Unit Price: USD $1.433687
≥1 USD $1.433687
≥200 USD $0.572424
≥500 USD $0.552731
≥1000 USD $0.543541
Inventory: 4016
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Beryllium Copper
Mounting Type Through Hole
Surface Mount NO

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
Series 209
JESD-609 Code e4
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Number of Positions 7
Voltage - Rated 20VDC
HTS Code 8536.50.90.65
Current Rating (Amps) 100mA
Pitch 0.100 2.54mm Full
Contact Finish Gold
Termination Style PC Pin
Actuator Type Slide (Standard)
Circuit SPST
Contact Current(DC)-Max 0.1A
Sealing BOTTOM SEALED
Contact Voltage(DC)-Max 20V
Electrical Life 2,000 Cycles
Switch Type SLIDE DIP SWITCH
Number of Switch Sections 7
Washable No
Actuator Level Raised

Dimensions

Length 0.758 19.25mm
Body Height 3.8mm
Height Above Board 0.204 5.18mm

Compliance

RoHS Status RoHS Compliant
