CRD16CW1AB

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / DIP Switches
Description Rotary with Knob CRD 16 Through Hole Right Angle Dip Switch 0m 0.4VA 20V 100mOhm
PDF
/
Buying Options
Total Price: USD $12.44
Unit Price: USD $12.439728
≥1 USD $12.439728
≥200 USD $4.814404
≥500 USD $4.64504
≥1000 USD $4.561015
Inventory: 7125
Minimum: 1
-
+

Technical Details

Technical

Series CRD
Feature Process Sealed
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Number of Positions 16
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Voltage - Rated 20VAC/DC
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA
Pitch 0.100 2.54mm Full
Orientation Right Angle
Terminal Pitch 2.54mm
Contact Finish Gold
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Rotary with Knob
Circuit Hexadecimal Complement
Contact Resistance 100mOhm
Max Voltage Rating (AC) 20V
Electrical Life 20,000 Steps
Throw Configuration SP16T
Max Voltage Rating (DC) 20V
Mechanical Life 30,000 Steps
Washable Yes
Actuator Level Raised
Published 2010
Packaging Tube
Operating Temperature -20°C~85°C

Dimensions

Length 0.393 10.00mm
Actuator Length 0m
Height Above Board 0.414 10.51mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant

Physical

Actuator Material Polybutylene
Body Material Polyphenylene Sulfide (PPS)
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Contact Material Beryllium Copper

Supply Chain

Factory Lead Time 16 Weeks
