BB149A,115
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - Variable Capacitance (Varicaps, Varactors)
Description
Tape & Reel (TR) Surface Mount Single 2 Varactors 2.225pF @ 28V 1MHz 10.9 30V 19.74pF
PDF
/
Buying Options
Total Price: USD $25.78
Unit Price: USD $25.7849
≥1 USD $25.7849
≥10 USD $21.15745
≥100 USD $20.49625
≥500 USD $19.83505
≥1000 USD $19.17385
Inventory: 7210
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Cap Tolerance 7.7%
Capacitance Ratio Condition C1/C28
Capacitance Ratio 10.9
Diode Capacitance-Nom 19.74pF
Frequency Band ULTRA HIGH FREQUENCY
Breakdown Voltage-Min 30V
Voltage - Peak Reverse (Max) 30V
Capacitance @ Vr, F 2.225pF @ 28V 1MHz
Diode Type Single
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G2
Pin Count 2
Base Part Number BB149
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Varactors
HTS Code 8541.10.00.70
Additional Feature 2% MATCHED SETS OF 10 DIODES ARE AVAILABLE
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case SC-76, SOD-323
Mounting Type Surface Mount
