BAP50-03-TP
RoHS
RoHS compliant
RoHS compliantPackage SC-76, SOD-323
Category Discrete Semiconductor Products / Diodes - RF
Description
RF DIODE PIN 50V 200MW SOD323
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
≥10 USD $0.28424
≥100 USD $0.248864
≥500 USD $0.16104
≥1000 USD $0.133338
≥3000 USD $0.106656
Inventory: 63953
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Diode Forward Resistance-Max 5Ohm
Diode Capacitance-Max 1.11pF
Resistance @ If, F 5Ohm @ 10mA 100MHz
Voltage - Peak Reverse (Max) 50V
Capacitance @ Vr, F 0.35pF @ 5V 1MHz
Current - Max 50mA
Diode Type PIN - Single
Power Dissipation-Max 200mW
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G2
Pin Count 2
Base Part Number BAP50
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology POSITIVE-INTRINSIC-NEGATIVE
HTS Code 8541.10.00.80
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tape & Reel (TR)
Operating Temperature -65°C~150°C TJ
Physical
Diode Element Material SILICON
Surface Mount YES
Package / Case SC-76, SOD-323
Supply Chain
Factory Lead Time 12 Weeks
