VS-SD553C45S50L
RoHS
RoHS compliant
RoHS compliantPackage DO-200AB, B-PUK
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE MODULE 4.5KV 560A DO200AB
PDF
/
Buying Options
Total Price: USD $311.68
Unit Price: USD $311.678521
≥1 USD $311.678521
≥201 USD $124.361827
≥501 USD $120.206498
≥999 USD $118.153123
Inventory: 2162
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Recovery Time 5 μs
Reverse Voltage 45V
Peak Non-Repetitive Surge Current 12.57kA
Max Repetitive Reverse Voltage (Vrrm) 45V
Peak Reverse Current 75mA
Reverse Recovery Time 5 μs
Number of Phases 1
Average Rectified Current 560A
Max Reverse Voltage (DC) 4.5kV
Voltage - DC Reverse (Vr) (Max) 4500V
Application HIGH VOLTAGE HIGH POWER FAST SOFT RECOVERY
Max Surge Current 12.57kA
Forward Current 560A
Voltage - Forward (Vf) (Max) @ If 3.24V @ 1500A
Current - Reverse Leakage @ Vr 75mA @ 4500V
Diode Type Standard
Speed Standard Recovery >500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Terminal Position END
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, SNUBBER DIODE
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2007
Packaging Bulk
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-200AB, B-PUK
Mounting Type Clamp On
Mount Chassis Mount, Screw
