SS8PH10-E3/87A
RoHS
RoHS compliant
RoHS compliantPackage TO-277, 3-PowerDFN
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Schottky Diodes & Rectifiers 8.0 Amp 100 Volt
PDF
/
Inventory: 4798
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 175°C
Min Operating Temperature -55°C
Base Part Number SS8PH10
Polarity Standard
Element Configuration Common Anode
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 2μA @ 100V
Output Current 8A
Voltage - Forward (Vf) (Max) @ If 900mV @ 8A
Max Reverse Leakage Current 2μA
Operating Temperature - Junction -55°C~175°C
Max Surge Current 150A
Voltage - DC Reverse (Vr) (Max) 100V
Current - Average Rectified (Io) 8A
Forward Voltage 900mV
Max Reverse Voltage (DC) 100V
Average Rectified Current 8A
Peak Non-Repetitive Surge Current 150A
Packaging Tape & Reel (TR)
Published 2008
Series eSMP?
Part Status Obsolete
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-277, 3-PowerDFN
Number of Pins 3
Supplier Device Package TO-277A (SMPC)
