MBRS120T3H

ON Semiconductor
RoHS
/
Package DO-214AA, SMB
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description DO-214AA SMB Surface Mount Schottky Fast Recovery =< 500ns > 200mA (Io) Diode Schottky 600mV @ 1A 1A 20V -65C~125C
PDF
/
Inventory: 1409
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case DO-214AA, SMB

Technical

Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Speed Fast Recovery =< 500ns, > 200mA (Io)
Diode Type Schottky
Current - Reverse Leakage @ Vr 1mA @ 20V
Voltage - Forward (Vf) (Max) @ If 600mV @ 1A
Operating Temperature - Junction -65°C~125°C
Voltage - DC Reverse (Vr) (Max) 20V
Current - Average Rectified (Io) 1A

Compliance

RoHS Status Non-RoHS Compliant
