MBR1060H
RoHS
/
Package TO-220-2
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE SCHOTTKY
PDF
/
Inventory: 9964
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Reverse Current-Max 100μA
Non-rep Pk Forward Current-Max 150A
JEDEC-95 Code TO-220AC
Rep Pk Reverse Voltage-Max 60V
Number of Phases 1
Current - Average Rectified (Io) 10A
Voltage - DC Reverse (Vr) (Max) 60V
Application GENERAL PURPOSE
Output Current-Max 5A
Operating Temperature - Junction -65°C~175°C
Case Connection CATHODE
Voltage - Forward (Vf) (Max) @ If 800mV @ 10A
Current - Reverse Leakage @ Vr 100μA @ 60V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Power Dissipation-Max 2W
Configuration COMMON CATHODE, 2 ELEMENTS
Number of Elements 2
Operating Temperature (Max) 150°C
JESD-30 Code R-PSFM-T2
Reference Standard MIL-19500
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Additional Feature HIGH RELIABILITY
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 2
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Obsolete
JESD-609 Code e0
Series SWITCHMODE?
Physical
Diode Element Material SILICON
Surface Mount NO
Package / Case TO-220-2
Mounting Type Through Hole
