ISO1176DWG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Isolators / Digital Isolators
Description
DGT ISO 2.5KV RS422/RS485 16SOIC
PDF
/
Buying Options
Total Price: USD $14.7
Unit Price: USD $14.699228
≥1 USD $14.699228
≥200 USD $5.864724
≥480 USD $5.669102
≥1000 USD $5.571948
Inventory: 9221
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 10.3mm
Height 2.65mm
Technical
Isolated Power No
Output Low Current-Max 0.008A
Inputs - Side 1/Side 2 2/1
Supply Voltage1-Nom 5V
Transmit Delay-Max 40 ns
Common Mode Transient Immunity (Min) 25kV/μs
Simplex/Duplex Half Duplex
Receive Delay-Max 55 ns
Number of Transceivers 1
Interface Standard EIA-485; TIA-485
Receiver Number of Bits 1
Channel Type Unidirectional
Driver Number of Bits 1
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Differential Output YES
Data Rate 40Mbps
Logic Function Transceiver
Propagation Delay 80 ns
Operating Supply Current 10mA
Number of Channels 3
Working Voltage 560V
Operating Supply Voltage 3.3V
Voltage - Isolation 2500Vrms
Pin Count 16
Base Part Number ISO1176
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.15V~5.5V 4.75V~5.25V
Technology Capacitive Coupling
Max Power Dissipation 220mW
Subcategory Line Driver or Receivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type RS422, RS485
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 547.485991mg
Number of Pins 16
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 12 Weeks
