RDC4072D12
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-12V 40W
PDF
/
Buying Options
Total Price: USD $140
Unit Price: USD $140
≥1 USD $140
≥10 USD $132.07547
Inventory: 50
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 6-DIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2014
Series RDC (40W)
Size / Dimension 2.00Lx1.60W x 0.42 H 50.8mmx40.6mmx10.7mm
Feature Remote On/Off, OCP, OTP, OVP, SCP, UVLO
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Isolated Module
Applications ITE (Commercial), Railway
Max Power Dissipation 40W
Depth 50.8mm
Number of Outputs 2
Efficiency 87%
Voltage - Isolation 1.5kV
Max Output Current 1.65A
Voltage - Output 1 12V
Current - Output (Max) 1.65A 1.65A
Output Power 40W
Control Features Enable, Active High
Voltage - Output 2 -12V
Current - Output 1 1.65A
Max Output Power 40W
Current - Output 2 1.65A
Max Input Voltage (DC) 140V
Min Input Voltage (DC) 36V
Dimensions
Height 10.668mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
