JCD0505D03
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER JCD0505D03 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 4.5 V, 9 V, 5 W, 3.3 V
PDF
/
Buying Options
Total Price: USD $23.85
Unit Price: USD $23.85
≥1 USD $23.85
≥10 USD $22.5
≥100 USD $21.22642
≥1000 USD $18.89143
Inventory: 6593
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Height 10.4mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 9V
Current - Output 2 750mA
Nominal Output Voltage -3.3V
Max Output Power 5W
Current - Output 1 750mA
Voltage - Output 2 -3.3V
Output Power 5W
Output Current 750mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Max Output Current 750mA
Output Voltage 3.3V
Voltage - Isolation 1.6kV
Efficiency 76%
Number of Outputs 2
JESD-30 Code R-XDMA-P8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 31.75mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 5W
Power Rating 5W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.4mm
Series JCD (5W)
Published 2007
Packaging Tube
Operating Temperature -40°C~100°C
Physical
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
