ISV0212S15
RoHS
/
Package 6-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER
PDF
/
Buying Options
Total Price: USD $13.78
Unit Price: USD $13.78
≥1 USD $13.78
≥10 USD $13
≥100 USD $12.26415
Inventory: 143
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 6-SMD Module
Technical
Operating Temperature -40°C~75°C
Series ISV02 (2W)
Size / Dimension 0.58Lx0.57W x 0.35 H 14.7mmx14.4mmx9.0mm
Feature Remote On/Off
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 2W
Reach Compliance Code compliant
Number of Outputs 1
Efficiency 81%
Voltage - Isolation 3kV
Voltage - Input (Max) 18V
Voltage - Output 1 15V
Voltage - Input (Min) 4.5V
Current - Output (Max) 133mA
