ISB0105D12
RoHS
/
Package 14-SMD Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
XP POWER ISB0105D12 Isolated Board Mount DC/DC Converter, Fixed, 2 Output, 4.5 V, 9 V, 1 W, 12 VNew
PDF
/
Buying Options
Total Price: USD $20.22
Unit Price: USD $20.2248
≥1 USD $20.2248
≥10 USD $19.08
≥100 USD $18
≥500 USD $16.98113
≥1000 USD $16.01994
Inventory: 2832
Minimum: 1
-
+
Technical Details
Compliance
REACH SVHC Unknown
Dimensions
Length 18.9mm
Height 8.382mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 9V
Current - Output 2 42mA
Max Output Power 1W
Current - Output 1 42mA
Voltage - Output 2 -12V
Control Features Enable, Active Floating
Output Power 1W
Current - Output (Max) 42mA 42mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Output 1 12V
Max Output Current 42mA
Output Voltage 12V
Voltage - Isolation 1.5kV
Efficiency 79%
Number of Outputs 2
JESD-30 Code R-PSMA-G7
Reach Compliance Code compliant
Depth 13.7mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 7
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 0.74Lx0.54W x 0.33 H 18.9mmx13.7mmx8.5mm
Series ISB01 (1W)
Published 2015
Packaging Bulk
Operating Temperature -40°C~95°C
Physical
Package / Case 14-SMD Module, 7 Leads
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
