TMR 3-2421
RoHS
RoHS compliant
RoHS compliantPackage 8-SIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-5V 3W
PDF
/
Buying Options
Total Price: USD $19.17
Unit Price: USD $19.1664
≥1 USD $19.1664
≥10 USD $18.87072
≥100 USD $18.576096
≥500 USD $17.69152
≥1000 USD $16.217256
≥3000 USD $15.922403
Inventory: 545
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 11.1mm
Technical
Total Power Output-Max 3W
Voltage - Output 2 -5V
Current - Output (Max) 300mA 300mA
Trim/Adjustable Output NO
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 5V
Output Voltage 5V
Voltage - Input (Max) 36V
Voltage - Isolation 1.6kV
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 2
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Subcategory Other Analog ICs
Additional Feature -5 VOLT ADDITIONAL OUTPUT IS AVAILABLE
Power (Watts) 3W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 7
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Remote On/Off, SCP
Size / Dimension 0.86Lx0.36W x 0.44 H 21.8mmx9.2mmx11.1mm
Series TMR 3 (3W)
Published 2007
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 8-SIP Module, 7 Leads
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
