THN 15-1223
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 15W
PDF
/
Buying Options
Total Price: USD $37.98
Unit Price: USD $37.9808
≥1 USD $37.9808
≥10 USD $37.34808
≥100 USD $36.16272
≥500 USD $34.384064
≥1000 USD $32.012816
≥3000 USD $31.538531
Inventory: 1201
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 10.4mm
Technical
Total Power Output-Max 15W
Voltage - Output 2 -15V
Current - Output (Max) 500mA 500mA
Trim/Adjustable Output NO
Input Voltage-Nom 12V
Voltage - Input (Min) 9V
Voltage - Output 1 15V
Output Voltage 15V
Voltage - Input (Max) 18V
Voltage - Isolation 1.5kV
Efficiency 88%
Number of Outputs 2
JESD-30 Code S-MDMA-T6
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology HYBRID
Power (Watts) 15W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Remote On/Off, OVP, SCP
Size / Dimension 1.00Lx1.00W x 0.39 H 25.4mmx25.4mmx9.9mm
Series THN 15 (15W)
Published 2012
Operating Temperature -40°C~85°C With Derating
Physical
Surface Mount NO
Package / Case 6-DIP Module
Mounting Type Through Hole
Supply Chain
Factory Lead Time 13 Weeks
