THB 6-4823
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 6 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER +/-15V 6W
PDF
/
Buying Options
Total Price: USD $56.81
Unit Price: USD $56.81146
≥1 USD $56.81146
≥10 USD $53.59572
≥100 USD $50.562
≥500 USD $47.7
≥1000 USD $45
≥3000 USD $42.45283
Inventory: 4123
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Through Hole
Package / Case 24-DIP Module, 6 Leads
Surface Mount NO
Technical
Operating Temperature -40°C~71°C With Derating
Published 2012
Series THB 6 (6W)
Size / Dimension 1.25Lx0.80W x 0.47 H 31.8mmx20.3mmx12.0mm
JESD-609 Code e4
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 7
ECCN Code EAR99
Type Isolated Module
Terminal Finish GOLD
Applications ITE (Commercial), Medical
Power (Watts) 6W
Technology HYBRID
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDMA-T7
Number of Outputs 2
Efficiency 80%
Voltage - Isolation 3kV
Voltage - Input (Max) 75V
Output Voltage 15V
Voltage - Output 1 15V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output NO
Current - Output (Max) 200mA 200mA
Voltage - Output 2 -15V
Total Power Output-Max 6W
Dimensions
Length 31.8mm
Compliance
RoHS Status ROHS3 Compliant
