TPS82677SIPT
RoHS
RoHS compliant
RoHS compliantPackage 8-BGA Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC CONVERTER 1.2V 0.72W
PDF
/
Buying Options
Total Price: USD $2.68
Unit Price: USD $2.6847
≥1 USD $2.6847
≥10 USD $2.20305
≥100 USD $2.13465
≥500 USD $2.0653
≥1000 USD $1.9969
Inventory: 10090
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 950μm
Width 2.3mm
Length 2.9mm
Height 1mm
Technical
Switching Frequency 5.45MHz
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Control Features Enable, Active High
Quiescent Current 17μA
Output Current 600mA
Input Voltage-Nom 3.6V
Voltage - Input (Min) 2.3V
Max Output Current 600mA
Output Voltage 1.2V
Voltage - Input (Max) 4.8V
Efficiency 90%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 8
Base Part Number TPS82677
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Subcategory Switching Regulator or Controllers
Additional Feature ALSO HAS CONTROL TECHNIQUE OF PFM
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Remote On/Off, OCP, OTP, UVLO
Size / Dimension 0.12Lx0.09W x 0.04 H 3.0mmx2.4mmx1.0mm
Series MicroSip?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-BGA Module
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 12 Weeks
