PTD08A010WAG

Texas Instruments
RoHS
RoHS RoHS compliant
Package 12-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description MODULE DGTL POWERTRAIN 10A 12SMD
PDF
/
Inventory: 10000
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-SMD Module
Number of Pins 12

Technical

Operating Temperature -40°C~85°C
Packaging Tray
Series Powertrain?
Feature Remote On/Off, OCP, OTP, UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 36W
Technology HYBRID
Terminal Position UNSPECIFIED
Terminal Form UNSPECIFIED
Number of Functions 1
Base Part Number TD08A010
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 95%
Voltage - Input (Max) 14V
Output Voltage 3.6V
Max Output Current 10A
Voltage - Output 1 0.7V~3.6V
Voltage - Input (Min) 4.75V
Input Voltage-Nom 12V
Trim/Adjustable Output YES
Output Current 10A

Compliance

RoHS Status ROHS3 Compliant
