PTB78560AAH
RoHS
RoHS compliant
RoHS compliantPackage 11-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 3.6V to 5.5V 0.25A to 8A 30W 11-Pin DIP Module
PDF
/
Buying Options
Total Price: USD $63.87
Unit Price: USD $63.8704
≥1 USD $63.8704
≥10 USD $63.37056
≥100 USD $62.87087
≥500 USD $60.87473
≥1000 USD $57.880715
≥3000 USD $53.889
Inventory: 62
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 9.73mm
Height 9.98mm
Technical
Isolation Isolated
Min Output Voltage 3.6V
Current - Output 1 6A
Max Output Voltage 5.5V
Output Power 30W
Output Current 6A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 3.6V~5.5V
Max Output Current 6A
Output Voltage 5V
Voltage - Input (Max) 60V
Voltage - Isolation 1.5kV
Efficiency 83%
Number of Outputs 1
Pin Count 11
Base Part Number PTB78560
Depth 26.54mm
Number of Functions 1
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 30W
Power Rating 30W
Applications ITE (Commercial)
Terminal Finish Tin (Sn)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 11
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Not For New Designs
JESD-609 Code e3
Size / Dimension 2.05Lx1.05W x 0.39 H 52.1mmx26.7mmx10.0mm
Series PTB78560 (30W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 11
Surface Mount NO
Package / Case 11-DIP Module
Mounting Type Through Hole
Supply Chain
Lifecycle Status NRND (Last Updated: 5 days ago)
Alternative Model
