PT6881C
RoHS
RoHS compliant
RoHS compliantPackage 18-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 5A
PDF
/
Buying Options
Total Price: USD $19.45
Unit Price: USD $19.448
≥1 USD $19.448
Inventory: 179
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height 10.922mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 5A
Input Voltage-Nom 28V
Voltage - Input (Min) 15V
Max Output Current 5A
Output Voltage 3.3V
Voltage - Input (Max) 33V
Efficiency 73%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 18
Base Part Number PT6881
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.65mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 17W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Remote On/Off
Size / Dimension 2.00Lx1.19W x 0.43 H 50.8mmx30.2mmx10.9mm
Series Excalibur? PT6880
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 18
Package / Case 18-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
