PT6683R
RoHS
RoHS compliant
RoHS compliantPackage 14-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 5Vout 5 Amp 18-36V Inp Adj Int Sw Reg
PDF
/
Buying Options
Total Price: USD $37.18
Unit Price: USD $37.175932
≥1 USD $37.175932
≥10 USD $35.071637
≥100 USD $33.086444
≥500 USD $31.213631
≥1000 USD $29.446823
Inventory: 1115
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 10.7mm
Length 62.48mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 600kHz
Switcher Configuration SINGLE
Control Mode VOLTAGE-MODE
Output Current 5A
Input Voltage-Nom 28V
Voltage - Input (Min) 18V
Max Output Current 5A
Output Voltage 5V
Voltage - Input (Max) 36V
Efficiency 82%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number PT6683
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 30.98mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 25W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PT6680
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 14
Package / Case 14-SIP Module
Mounting Type Through Hole
Mount Through Hole
