PT6473N
RoHS
/
Package 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG 2.0V 14A 3.3VIN ADJ VERT
PDF
/
Inventory: 3428
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 12-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT6470
Size / Dimension 1.71Lx0.48W x 0.68 H 43.4mmx12.2mmx17.3mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 28W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Base Part Number PT6473
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 92%
Voltage - Input (Max) 3.65V
Max Output Current 14A
Voltage - Output 1 2V
Voltage - Input (Min) 2.95V
Input Voltage-Nom 3.3V
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK
Switching Frequency-Max 300kHz
Dimensions
Height 17.272mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
