78ST109SC
RoHS
/
Package 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 9.00V SMD
PDF
/
Inventory: 2965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Height 8.636mm
Technical
Switching Frequency-Max 700kHz
Switcher Configuration BUCK
Voltage - Input (Min) 7V
Voltage - Output 1 9V
Max Output Current 1.5A
Voltage - Input (Max) 30V
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-G3
Pin Count 3
Base Part Number 78ST109
Reach Compliance Code unknown
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 13.5W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature OTP, SCP
Size / Dimension 0.94Lx0.90W x 0.34 H 23.9mmx22.9mmx8.6mm
Series 78ST100
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 3-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
