PAH75D24-3325/PV
RoHS
/
Package 9-DIP Module, 1/2 Brick
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 60W 3.3V 1.8V 15A
PDF
/
Inventory: 1618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 9-DIP Module, 1/2 Brick
Number of Pins 10
Technical
Operating Temperature -40°C~100°C
Packaging Bulk
Published 2012
Series PAH75D
Size / Dimension 2.40Lx2.28W x 0.50 H 61.0mmx57.9mmx12.7mm
Feature Remote On/Off, OCP, OVP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 75W
Subcategory Other Analog ICs
Max Power Dissipation 60W
Technology HYBRID
Terminal Position DUAL
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 78%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 3.3V
Max Output Current 15A
Voltage - Output 1 3.3V
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Current - Output (Max) 15A 15A
Output Current 15A
Output Power 60W
Control Features Enable, Active High
Voltage - Output 2 2.5V
Current - Output 1 15A
Current - Output 2 15A
Dimensions
Height 12.7mm
Compliance
RoHS Status RoHS Compliant
