REC5-4809SRWZ/H6/A/M/CTRL
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP Module, 8 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 5W 18-72VIN 09VOUT
PDF
/
Buying Options
Total Price: USD $36.61
Unit Price: USD $36.61183
≥1 USD $36.61183
≥10 USD $34.53946
≥100 USD $32.5844
≥500 USD $30.74
≥1000 USD $29
≥3000 USD $27.35849
Inventory: 3258
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 20.3mm
Length 32mm
Height 10.2mm
Technical
Nominal Input Voltage 48V
Total Power Output-Max 5W
Max Output Voltage 9V
Control Features Enable, Active Low
Output Power 5W
Output Current 556mA
Trim/Adjustable Output NO
Input Voltage-Nom 48V
Voltage - Input (Min) 18V
Max Output Current 556mA
Output Voltage 9V
Voltage - Input (Max) 72V
Voltage - Isolation 6kV
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MDMA-P9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 5W
Subcategory Other Analog ICs
Applications ITE (Commercial), Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 9
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Remote On/Off, SCP
Size / Dimension 1.26Lx0.80W x 0.40 H 32.0mmx20.3mmx10.2mm
Series ECONOLINE REC5 (5W)
Packaging Tube
Operating Temperature -40°C~75°C
Physical
Weight 13g
Package / Case 24-DIP Module, 8 Leads
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
