RB-3.324D

Recom Power
RoHS
RoHS RoHS compliant
Package 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 1W 3.3VIN +/-24VOUT
PDF
/
Buying Options
Total Price: USD $7.55
Unit Price: USD $7.5472
≥1 USD $7.5472
≥10 USD $7.12
≥100 USD $6.71698
≥500 USD $6.33677
Inventory: 3439
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length 19.6mm
Height 10.2mm

Technical

Nominal Input Voltage 3.3V
Total Power Output-Max 0.504W
Voltage - Output 2 -24V
Max Output Voltage 24V
Output Power 1W
Output Current 21mA
Current - Output (Max) 21mA 21mA
Trim/Adjustable Output NO
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3V
Max Output Current 21mA
Output Voltage 24V
Voltage - Input (Max) 3.6V
Voltage - Isolation 1kV
Efficiency 84%
Qualification Status Not Qualified
Number of Outputs 2
JESD-30 Code R-XSMA-P5
Pin Count 7/5
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.40 H 19.7mmx6.0mmx10.2mm
Series ECONOLINE RB (1W)
Packaging Tube
Operating Temperature -40°C~85°C

Physical

Weight 2.2g
Package / Case 7-SIP Module, 5 Leads
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Factory Lead Time 9 Weeks
