R24P209D/P
RoHS
RoHS compliant
RoHS compliantPackage 7-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 2W 24VIN +/-09VOUT
PDF
/
Buying Options
Total Price: USD $15.08
Unit Price: USD $15.0832
≥1 USD $15.0832
≥10 USD $14.5992
≥100 USD $13.9216
≥500 USD $13.508
≥1000 USD $13.3056
≥3000 USD $12.936088
Inventory: 409
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 7-SIP Module, 5 Leads
Number of Pins 5
Weight 4.3g
Technical
Operating Temperature -40°C~90°C
Packaging Tube
Series ECONOLINE RxxP2xx (2W)
Size / Dimension 0.77Lx0.39W x 0.49 H 19.6mmx9.9mmx12.4mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial), Medical
Subcategory Other Analog ICs
Max Power Dissipation 2W
Technology HYBRID
Terminal Position SINGLE
Terminal Form PIN/PEG
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 9.8mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 7/5
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 75%
Voltage - Isolation 6.4kV
Voltage - Input (Max) 26.4V
Output Voltage 9V
Max Output Current 111mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Current - Output (Max) 111mA 111mA
Output Current 111mA
Output Power 2W
Max Output Voltage 9V
Voltage - Output 2 -9V
Total Power Output-Max 2W
Nominal Input Voltage 24V
Isolation Isolated
Dimensions
Height 12.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
