R1S-2424
RoHS
RoHS compliant
RoHS compliantPackage 8-SMD Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 1W 24VIN 24VOUT
PDF
/
Buying Options
Total Price: USD $10.2
Unit Price: USD $10.1951
≥1 USD $10.1951
≥10 USD $9.61802
≥100 USD $9.0736
≥500 USD $8.56
≥1000 USD $8.07547
Inventory: 1450
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SMD Module, 5 Leads
Number of Pins 5
Weight 1g
Technical
Operating Temperature -40°C~100°C
Packaging Tube
Series ECONOLINE R1S (1W)
Size / Dimension 0.50Lx0.42W x 0.28 H 12.8mmx10.7mmx7.0mm
Feature SCP
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 1W
Technology HYBRID
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 255
Number of Functions 1
Depth 10.7mm
Time@Peak Reflow Temperature-Max (s) 5
Pin Count 8/5
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 84%
Voltage - Isolation 1kV
Voltage - Input (Max) 26.4V
Output Voltage 24V
Max Output Current 42mA
Voltage - Input (Min) 21.6V
Input Voltage-Nom 24V
Trim/Adjustable Output NO
Output Current 42mA
Output Power 1W
Max Output Voltage 24V
Total Power Output-Max 1W
Nominal Input Voltage 24V
Isolation Isolated
Dimensions
Height 6.7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
