EC4BE06
RoHS
RoHS compliant
RoHS compliantPackage 5-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Isolated DC/DC Converters 10W, 2.00x1.00x0.40 9-18Vin, +/-5Vout
PDF
/
Inventory: 4675
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Through Hole
Package / Case 5-DIP Module
Technical
Operating Temperature -40°C~100°C With Derating
Published 2005
Series EC4BE (10W)
Size / Dimension 2.00Lx1.00W x 0.40 H 50.8mmx25.4mmx10.2mm
Feature SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 10W
Subcategory Other Analog ICs
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 78%
Voltage - Isolation 500V
Voltage - Input (Max) 18V
Output Voltage 5V
Voltage - Output 1 5V
Voltage - Input (Min) 9V
Current - Output (Max) 1A 1A
Output Power 5W
Voltage - Output 2 -5V
Current - Output 1 1A
Nominal Input Voltage 12V
Current - Output 2 1A
Compliance
RoHS Status ROHS3 Compliant
