EC2SA12N image
Favorite
EC2SA12N image
Favorite
RoHS
RoHS RoHS compliant
Package 6-SIP Module, 5 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description Isolated DC/DC Converters DC-DC 2W Unregulated 12Vin, 12Vout
PDF
/
Buying Options
Total Price: USD $8.61
Unit Price: USD $8.6064
≥1 USD $8.6064
≥10 USD $8.54128
≥100 USD $8.47616
≥500 USD $8.34592
≥1000 USD $8.085264
≥3000 USD $7.302768
Inventory: 266
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Current - Output (Max) 167mA
Voltage - Input (Min) 10.8V
Voltage - Output 1 12V
Output Voltage 12V
Voltage - Input (Max) 13.2V
Voltage - Isolation 1kV
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
Terminal Pitch 2.54mm
Terminal Position SINGLE
Subcategory Other Analog ICs
Power (Watts) 2W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 5
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.28W x 0.40 H 19.6mmx7.2mmx10.2mm
Series EC2SAN (2W)
Operating Temperature -40°C~85°C With Derating

Physical

Surface Mount NO
Package / Case 6-SIP Module, 5 Leads
Mounting Type Through Hole

Supply Chain

Factory Lead Time 8 Weeks
